Precision Investment Casting of Stainless Steel

Precision Investment Casting of Stainless Steel

Material: Cast Stainless Steel
Process: Precision Investment Casting + CNC Machining
Weight: 2.20 kg
Application: Manifold Exhaust

OEM Custom Precision Investment Casting Manifold Exhaust of Stainless Steel with Machining Services, from Idea to the Markets.

Description

Precision Investment Casting Foundry with Machining Services, from Idea to the Markets.

Almost most of the ferrous and non ferrous metal and alloys could be cast by investment casting process. But, at our lost wax casting foundry, we mainly cast nickel base alloys, cobalt base alloys, carbon steel, alloy steel, stainless steel, super duplex stainless steel, gray cast iron, ductile cast iron, aluminium alloys and brass. Additionally, certain applications require the use of specialized other alloys used primarily in harsh environments. These alloys, such as Titanium and Vanadium, meet the additional demands that might not be achieved with standard Aluminum alloys. For example, Titanium alloys often are used to produce turbine blades and vanes for aerospace engines. Cobalt-base and Nickel-base alloys (with a variety of secondary elements added to achieve specific strength-strength, corrosion-strength and temperature-resistant properties), are additional types of cast metals.


Materials for Investment Casting Process at RMC Foundry

Category China Grade UK Grade US Grade Japan Grade Germany Grade
Carbon Steel ZG15, ZG20, ZG25, ZG35, ZG45, ZG55, Q235, Q345, Q420 A1, A3, A5, CLA1A, CLA1C, AM1
1008, 1015, 1018, 1020,
1025, 1030, 1035, 1040,
1045, 1050, 1060, 1070, WC6, WCC, WCB, WCA, LCB
SC360, SC450, SC480, SCW410, SCW450, SCW550, SCW620, SCC5, S15C, S20C, S25C, S45C, S50C 1.0570, 1.0558, 1.1191, 1.0619, 1.0446, GS38, GS45, GS52, GS60, 1.0601, C20, C25, C30, C45
Low Alloy Steel
20Mn, 45Mn, ZG20Cr, 40Cr, 20Mn5, 16CrMo4, 42CrMo,
40CrV, 20CrNiMo, GCr15, 9Mn2V
CLA2, CLA3, CLA4, CLA8, CLA5A, CLA5B, CLA9, CLA11, CLA12B, CLA12C, CLA13, CLA1B, EN1A, EN8, EN9, EN14, EN19, EN24, EN32B, PD100A, NCM3, NCM5, NCM8, NCM32 1117, 4130, 4140, 4340, 6150, 5140, WC6, LCB, Gr.13Q, 8620, 8625, 8630, 8640, H13 SCM415, SCM435, SCM440, SCM445, SKS3
GS20Mn5, GS15CrNi6, GS16MnCr5, GS25CrMo4V, GS42CrMo4, S50CrV4,
34CrNiMo6, 50CrMo4, G-X35CrMo17, 1.1131, 1.0037, 1.0122, 1.2162, 1.2542, 1.6511, 1.6523, 1.6580, 1.7131, 1.7132, 1.7218, 1.7225, 1.7227, 1.7228, 1.7231, 1.7321, 1.8519, ST37, ST52
Ferritic Stainless Steel 1Cr17, 022Cr12, 10Cr17, ANC1B 430, 431, 446, CA-15, CA6N, CA6NM SCS1, SCS1X, SCS3, CS3X, SCS4, SCS5, SCS6 1.4000, 1.4005, 1.4008, 1.4016, GX22CrNi17, GX4CrNi13-4
Martensitic Stainless Steel 1Cr13, 2Cr13, 3Cr13, 4Cr13, ANC1C, ANC2 410, 420, 430, 440B, 440C SCS2, SCS2A 1.4021, 1.4027, 1.4028, 1.4057, 1.4059, 1.4104, 1.4112, 1.4116, 1.4120, 1.4122, 1.4125
Austenitic stainless steel
06Cr19Ni10, 022Cr19Ni10,
06Cr25Ni20, 022Cr17Ni12Mo2, 03Cr18Ni16Mo5
ANC3A, ANC3B, ANC3ALC, ANC3AFC, ANC3BFC, ANC4B, ANC4BFC, ANC20, 316C12, 316S16, 316C16, 347C17 302, 303, 304, 304L, 316, 316L, 329, CF3, CF3M, CF8, CF8M, CN7M, CN3MN SCS11, SCS13, SCS14, SCS14A, SCS16, SCS16A, SCS18, SCS21, SCS35
1.3960, 1.4301, 1.4305, 1.4306, 1.4308, 1.4313, 1.4321, 1.4401, 1.4403, 1.4404, 1.4405, 1.4406, 1.4408, 1.4409, 1.4435, 1.4436, 1.4539, 1.4550, 1.4552, 1.4581,
1.4582, 1.4584,
Precipitation Hardening Stainless Steel 05Cr15Ni5Cu4Nb, 05Cr17Ni4Cu4Nb ANC20, ANC21, ANC22 630, 634, 17-4PH, 15-5PH, CB7Cu-1 SCS24, SCS32 1.4542
High Mn Steel ZGMn13-1, ZGMn13-3, ZGMn13-5 BW10 B2, B3, B4 SCMnH1, SCMnH11, SCMnH21 1.3802, 1.3966, 1.3301, 1.3302
Duplex Stainless Steel 022Cr22Ni5Mo3N, 022Cr25Ni6Mo2N
A 890 1C, A 890 1A, A 890 3A, A 890 4A, A 890 5A,
A 995 1B, A 995 4A, A 995 5A, 2205, 2507
SCS10, SCS11 1.4460, 1.4462, 1.4468, 1.4469, 1.4517, 1.4770
Tool Steel Cr12 A5, H12, S5 SKD11, SKH9, SKH51 1.2344, 1.3343, 1.4528, GXCrMo17, X210Cr13, GX162CrMoV12
Heat Resistant Steel
20Cr25Ni20, 16Cr23Ni13,
45Cr14Ni14W2Mo
ANC5A 309, 310, CK20, CH20, HK30 SCH1, SCH2, SCH11, SCH13, SCH15, SCH21, SCH22, SCH24, SCH41, 1.4826, 1.4828, 1.4855, 1.4865
Nickel Base Alloy ANC19
HASTELLY-C, HASTELLY-X, SUPPER22H, CW-2M, CW-6M, CW-12MW, CX-2MW, HX(66Ni-17Cr), MRE-2, NA-22H, NW-22, M30C, M-35-1,
Inconel 625
SCH43, SCH44, SCH45, 2.4815, 2.4879, 2.4680
Aluminum
Alloy
ZL101, ZL102, ZL104 ASTM A356, ASTM A413, ASTM A360 AC3A, AC4A, AC4C G-AlSi7Mg, G-Al12
Copper Alloy
H96, H85, H65, HPb63-3,
HPb59-1, QSn6.5-0.1, QSn7-0.2
CZ125, CZ102, CZ107, CZ124, CZ122 C21000, C23000, C27000, C34500, C37710, C86500, C87600, C87400, C87800, C52100, C51100 C2100, C2300, C2700, C3560, C3771, C5212, C5111 CuZn5, CuZn15, CuZn35, CuZn36Pb3, CuZn40Pb2, CuSn10P1, CuSn5ZnPb, CuSn5Zn5Pb5
Cobalt Base Alloy UMC50, 670, Grade 31 2.4778

▶ Raw Materials Available for Investment Casting (Lost Wax Casting Process)

  • Carbon Steel:  AISI 1020  - AISI 1060,
  • Steel Alloys: ZG20SiMn, ZG30SiMn, ZG30CrMo, ZG35CrMo, ZG35SiMn, ZG35CrMnSi, ZG40Mn, ZG40Cr, ZG42Cr, ZG42CrMo...etc on request.
  • Stainless Steel: AISI 304, AISI 304L, AISI 316, AISI 316L and other stainless steel grade.
  • Brass & Copper.
  • Other Materials and Standards on request

▶ Capabilities of Investment Casting

  • Max Size: 1,000 mm × 800 mm × 500 mm
  • Weight Range: 0.5 kg - 100 kg
  • Annual Capacity: 2,000 tons
  • Bond Materials for Shell Building: Silica Sol, Water Glass and their mixtures.
  • Tolerances: On Request.


▶ Main Production Procedure

  • Patterns & Tooling Design → Metal Die Making → Wax Injection → Slurry Assembly → Shell Building → De-Waxing  → Chemical Composition Analysis → Melting & Pouring → Cleaning, Grinding & Shot Blasting → Post Processing or Packing for Shipment

▶ Inspecting Lost Wax Castings

  • Spectrographic and manual quantitative analysis
  • Metallographic analysis
  • Brinell, Rockwell and Vickers hardness inspection
  • Mechanical property analysis
  • Low and normal temperature impact testing
  • Cleanliness inspection
  • UT, MT and RT inspection

▶ Post-Casting Process

  • Deburring & Cleaning
  • Shot Blasting / Sand Peening
  • Heat Treatment: Normalization, Quench, Tempering, Carburization, Nitriding
  • Surface Treatment: Passivation, Andonizing, Electroplating, Hot Zinc Plating, Zinc Plating, Nickel Plating, Polishing, Electro-Polishing, Painting, GeoMet, Zintec.
  • Machining: Turning, Milling, Lathing, Drilling, Honing, Grinding.

▶ Why You Choose RMC for Custom Lost Wax Casting Parts?

  • Full solution from one single supplier ranging customized pattern design to finished castings and secondary process including machining, heat treatment and surface treatment.
  • Costdown proposals from our professional engineers based on your unique requirement.
  • Short leadtime for prototype, trial casting and any possible technical improvement.
  • Bonded Materials: Silica Col, Water Glass and their mixtures.
  • Manufacturing flexibility for small orders to mass orders.
  • Strong outsourcing manufacturing capabilities.

▶ General Commerial Terms

  • Main workflow: Inquiry & Quotation → Confirming Details / Cost Reduction Proposals → Tooling Development → Trial Casting → Samples Approval → Trial Order → Mass Production → Continuous Order Proceeding
  • Leadtime: Estimatedly 15-25 days for tooling development and estimatedly 20 days for mass production.
  • Payment Terms: To be negotiated.
  • Payment methods: T/T, L/C, West Union, Paypal.
